Name: Trapezoid 760mm 5 Ribs PLC Roof Tile Roll Forming Machine
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Trapezoid 760
Price: 16,000.00 USD
Availability: InStock

Home > products > Roof Tile Roll Forming Machine >

Trapezoid 760mm 5 Ribs PLC Roof Tile Roll Forming Machine

760mm roof tile roll forming machine

760mm tile roll forming machine

PLC roof tile roll forming machine

Place of Origin:

CHINA MAINLAND

Brand Name:

CANGZHOU WILLING

Certification:

ISO CE

Model Number:

Trapezoid 760

Request A Quote

Product Details

Product Name:

Trapezoid 760 Roof Tile 5 Ribs Roll Forming Machine

After-sales Service Provided:

Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Field Maintenance And Repair Service,Field Installation

Raw Material:

PPGI/Galvanized Sheet

Voltage:

380/50Hz/3PH

Control System:

PLC

Speed:

15-25m/min

Thickness:

0.3mm-0.8mm

Power:

3Kw

Effective Width:

760mm

Hydraulic Station Power:

3KW

Highlight:

760mm roof tile roll forming machine

760mm tile roll forming machine

PLC roof tile roll forming machine

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

Negotiable

Packaging Details

40' FLC

Delivery Time

30 Working Days

Payment Terms

L/C, T/T, D/A, D/P

Supply Ability

25 Sets Per Month

380v 50hz corrugated Roofing Sheet Roll Forming Machine Stable Performance Long Life Span

Get Best Price

Video

Lightweight Roofing Sheet Roll Forming Machine Stable Performance Long Life Span

Get Best Price

Video

Big Wave 4m / Min Roof Tile Roll Forming Machine

Get Best Price

Video

Steel Structure Metal Roof Roll Forming Machine Metal Roof Making Machine

Get Best Price

86-317-2016816

Contact Now

Product Description

Trapezoid 760 Roof Tile 5 Ribs Roll Forming Machine

Trapezoid 760 is our company’s hot selling machine. Sell more than a dozen units every month. Due to the stable operation, high efficiency and low energy consumption of the machine, it can effectively save customers production costs and labor costs.

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized, PPGI, Aluminum
2	Raw Material Thickness	0.3-0.8mm
3	Working Speed	15-25/min
4	Roller Station	18 Raws
5	Dimension (LWH)	7500 mm1200 mm1200 mm
6	Machine Weight	4500 KG
7	Electrical Control System	Panasonic PLC
8	Drive Motor Power	3 KW
9	Hydraulic Station Power	3 KW
10	Power Supply	380V/60HZ/3 PH
11	Cutting Accuracy	±2 mm
12	Driving Mode	Single Chain 1 inch
13	Material of Shaft	70 mm 45#steel forged
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Application

This type of tile is suitable for all kinds of buildings, such as warehouses, apartments, shopping malls, laboratories, garages, garages and the interior and exterior wall decoration of large-span steel structure houses.

Advantage

This profile tiles are mostly used for roofing, wall and interior and exterior wall decoration of buildings, . It has light weight, high strength, rich color, convenient and fast construction, earthquake resistance, fire prevention, rainproof, and long life. It have been welcomed by the most of users.
