2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine

2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine

prepainted galvanized steel floor deck machine

floor deck roll forming machine with warranty

2025 steel floor deck forming equipment

Place of Origin:

CHINA MAINLAND

Brand Name:

FMS

Certification:

ISO CE

Contact Us
Request A Quote
2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine
2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine
Product Details
Product Name:
Galvanized Steel Floor Decking Roll Forming Lines Manufacturer
Size:
380v/50hz,3 Phases Or As Your Request
Weight:
8000 Kg
Cutting Type:
Hydraulic Cutting
Control System:
Motor, Pump, Engine, PLC
Key Selling Points:
Long Service Life
Feeding Width:
1200mm
Material Of Rollers:
#45 Steel With Hard Chrome Coating
Way Of Cutting:
Hydraulic Cutting
Rolling Thinckness:
0.8-1.5mm
Highlight:

prepainted galvanized steel floor deck machine

,

floor deck roll forming machine with warranty

,

2025 steel floor deck forming equipment

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
40' FLC
Delivery Time
30 Working Days
Payment Terms
L/C, T/T, D/A, D/P
Supply Ability
20 Sets Per Month
RELATED PRODUCTS
Good price 2025 factory price Prepainted Galvanized Steel Floor Deck Roll Forming Machine online Video

2025 factory price Prepainted Galvanized Steel Floor Deck Roll Forming Machine

Get Best Price
Good price 2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine online Video

2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine

Get Best Price
Good price 2025 high Strenth Steel Floor Deck Roll Forming Machine online Video

2025 high Strenth Steel Floor Deck Roll Forming Machine

Get Best Price
Good price 1.2mm Profile Pressing Dot Floor Deck Roll Forming Machine online Video

1.2mm Profile Pressing Dot Floor Deck Roll Forming Machine

Get Best Price
Contact Us
Contact Now
Product Description
2025 Prepainted Galvanized Steel Floor Deck Roll Forming Machine
Manufacturer Overview

The steel floor deck roll forming machine is designed to produce high-quality steel floor decks, also known as floor bearing steel plates. These decks are used to support concrete or insulating membranes in roof and floor systems, providing a structurally efficient solution with high peak strength and low cost.

Technical Specifications
Suitable Material
Material Width 1000/1250mm
Effective Width 600/850/915 mm
Material Thickness 0.8-1.5mm
Material Type Galvanized Steel Strip, Prepainted Galvanised Steel
Yield Strength 245Mpa
Main Machine Specifications
Shaft Diameter 95mm
Wall Panel Thickness 18mm
Base Specification H446*199
Main Motor 37KW hydraulic system
Forming Speed 0-10m/min
Forming Station 33 Stations
Blade Material Cr12 (Die Steel)
Roller Material 45# steel, CNC lathes, Heat Treated, hard Chrome Coated
Speed Regulation AC Inverter Speed Regulation
Driving Mode Reduction Motor + Chain Transmission
Cutting Mode Hydraulic Type, Post-cutting
Cutting Motor Hydra station/hydraulic motor
Measuring Mode Photoelectric Encoder
Control Mode PLC
Operation Mode Button + Touch Screen
Voltage 380V or 415V/50Hz/3Ph or 220V/60Hz/3Ph
Dimension 15M × 1.5M × 1.3M
Machine Weight 16500KG (15500KG)
Warranty & Guarantee
  • Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase (excluding electrical parts)
  • Repairs will not be performed during the guarantee period in the following circumstances:
    • Damage occurs due to natural disaster
    • Malfunction occurs due to user error
    • Malfunction occurs due to modifications
    • Malfunction occurs due to movement or shipment after installation
Payment Terms
  • 40% in advance as down payment
  • 60% paid before shipment processing
Delivery Information
  • FOB: Tianjin Xingang Port
  • Delivery Time: 30 days after down payment is received
