Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings

Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings

High Straight Level CZ Purlin Roll Forming Machine

Crush Resistance Automatic Purlin Roll Forming Machine

1.5-3MM Thickness Steel Purlin Roll Forming Machine

Place of Origin:

China

Brand Name:

FMS

Certification:

CE,ISO

Contact Us
Request A Quote
Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings
Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings
Product Details
Voltage:
380V 50HZ 3phase
Weight:
8500 Kg
Roller Material:
45# Steel Chrome
Thickness:
1.5-3MM
Cutting Type:
Hydraulic Cutting
Control System:
PLC
Key Selling Points:
Automatic
Production Capacity:
30 M/min
Main Motor Power:
7.5kw
Highlight:

High Straight Level CZ Purlin Roll Forming Machine

,

Crush Resistance Automatic Purlin Roll Forming Machine

,

1.5-3MM Thickness Steel Purlin Roll Forming Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Packaging Details
Main machine is nude,the computer control box is packed by plastic.
Delivery Time
30days
Payment Terms
T/T,Western Union,L/C
Supply Ability
20 sets per month
RELATED PRODUCTS
Good price High Efficiency CZ Purlin Roll Forming Machine with 45# Steel Rollers and High Straightness for Construction online Video

High Efficiency CZ Purlin Roll Forming Machine with 45# Steel Rollers and High Straightness for Construction

Get Best Price
Good price Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings online Video

Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings

Get Best Price
Good price CZ Purlin Roll Forming Machine with 18 Station Rollers, 380V/50HZ/3Phase Voltage and Cr12Mov Cutting Blade for High Efficiency online Video

CZ Purlin Roll Forming Machine with 18 Station Rollers, 380V/50HZ/3Phase Voltage and Cr12Mov Cutting Blade for High Efficiency

Get Best Price
Good price CZ Purlin Roll Forming Machine with 7000*1400*1500mm Size 8-12m/min Forming Speed and 1.5-3.0mm Thickness for Galvanized Steel online Video

CZ Purlin Roll Forming Machine with 7000*1400*1500mm Size 8-12m/min Forming Speed and 1.5-3.0mm Thickness for Galvanized Steel

Get Best Price
Contact Us
86-317-2016816
Contact Now
Product Description
Full Automatic Strip Steel C/Z/U Purlin Roll Forming Machine
Product Advantages
Our C/Z purlin interchangeable roll forming machine offers superior performance compared to competitors:
  • Produces purlins with exceptional straightness and crush resistance
  • Enables reverse lap capability for Z purlins, enhancing connection strength
  • Precision control via reduced motor and frequency regulation for speed, length, and positioning
  • Quick and easy interchangeability between C and Z profiles
Purlins are essential structural components in roofing systems, supporting rafters and roof beams. Our machine produces lightweight steel purlins that perfectly meet roof structure requirements while maintaining strength and durability.
Applications: Ideal for medium-sized industrial and civil construction projects including factories, warehouses, aircraft hangars, exhibition halls, theaters, stadiums, and commercial buildings as primary load-bearing structures.
Technical Specifications
Main motor power 7.5kw
Hydraulic motor power 4kw
Hydraulic Pressure 10-12MPa
Voltage 380V/50HZ/3Phase
Control System PLC (Delta brand)
Feeding Material Galvanized steel
Feeding Thickness 1.5-4.0mm
Speed 30-50m/min
Roller station 18 rows
Shaft diameter 80mm
Shaft material 45# steel
Roller material 45# steel
Cutter material Cr12 quenched
Dimension 11000*1200*1500mm
Weight about 6700 kg
Warranty & Guarantee
  • 1-year guarantee against manufacturing defects (excluding electrical components)
  • Warranty void in cases of:
    • Damage from natural disasters
    • User error or improper operation
    • Unauthorized modifications
    • Damage during relocation after installation
Payment Terms
  • 40% advance payment required
  • 60% balance payment before shipment
Delivery Information
FOB: Tianjin Xingang Port
Delivery Time: 30 days after receiving down payment
Full Automatic CZ Purlin Roll Forming Machine with High Straight Level Crush Resistance and 1.5-3MM Thickness for Industrial Buildings 0
