Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control

Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control

full automatic PLC control roll forming machine

corrugated IBR double layer former

double layer roll forming machine with warranty

Place of Origin:

China

Brand Name:

FMS

Certification:

CE,ISO

Model Number:

840/850

Contact Us
Request A Quote
Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control
Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control
Product Details
Raw Material:
PPGI/Galvanized Sheet
Thickness:
0.25-0.8MM
Shaft Material:
Material Is 45# Forge Steel
Product Name:
IBR And Corrugated Double Layer Roof Roll Forming Machine Full Automatic
Forming Speed:
8-15m/min
Main Motor Power:
5.5 KW
Electrical Hydraulic:
4 KW
Voltage:
380 V
Highlight:

full automatic PLC control roll forming machine

,

corrugated IBR double layer former

,

double layer roll forming machine with warranty

Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Main machine is nude,the computer control box is packed by plastic.
Delivery Time
30days
Payment Terms
T/T, Western Union
Supply Ability
30 sets per month
RELATED PRODUCTS
Good price 380v 50-60hz Roof Tile Roof Sheet Double Layer Roll Forming Machine online Video

380v 50-60hz Roof Tile Roof Sheet Double Layer Roll Forming Machine

Get Best Price
Good price Trapezoidal And corrugated Roof Sheet Double Layer Roof Roll Forming Machine online Video

Trapezoidal And corrugated Roof Sheet Double Layer Roof Roll Forming Machine

Get Best Price
Good price 2024 New 380V 60Hz 3Ph Double Layer Roof Roll Forming Machine 840 Trapezoidal And 836 online Video

2024 New 380V 60Hz 3Ph Double Layer Roof Roll Forming Machine 840 Trapezoidal And 836

Get Best Price
Good price IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof online Video

IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof

Get Best Price
Contact Us
86-317-2016816
Contact Now
Product Description
Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control
Product Specifications
Attribute Value
Raw material PPGI/Galvanized sheet
Thickness 0.25-0.8MM
Shaft material 45# forge steel
Product name IBR And Corrugated Double Layer Roof Roll Forming Machine Full Automatic
Forming speed 8-15m/min
Main Motor Power 5.5 KW
Electrical Hydraulic 4 KW
Voltage 380 V
Product Description

Corrugated Double Layer Roll Forming Machine Full Automatic PLC Control

The double layer rollformer produces a dual profile on the same machine, sharing the same de-coiler, drive trains and motors, but using different rolls and different cut offs. The double layer machine is particularly useful where operating or storage space is a problem. The machine however produces low volumes of product.

Technical Parameters
Material Thickness 0.25-0.8 mm
Working Speed 8-15 m/min
Roller Stations Upper layer 13 stations, Down layer 15 stations
Material of Roller 45# steel quenching process and chrome coated
Material of Main Shaft 45 steel forged
Main Motor Power 5.5 KW
Electrical Hydraulic Station Power 4 KW
Hydraulic Station Pressure 12.0 Mpa
Material of Cutter Cr12
Driving Mode Single chain 1 inch
Cutting accuracy ±2mm
Power Supply 380V, 60HZ, 3 PHASES
Corrugated and IBR Double Layer Roll Forming Machine Full Automatic Plc Control 0
