IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof

IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof

Place of Origin:

China

Brand Name:

FMS

Certification:

CE,ISO

Contact Us
Request A Quote
IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof
IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof
Product Details
Product Description:
Double Layer Panel Roll Forming Macihine Lines
Production Capacity:
15m/min
Key Selling Points:
Easy To Operate
Rollers Material:
GCr15,Cr12,SKD11 Quenching Treatment:HRC58-62（optional）
Control System:
PLC
Voltage:
380V 50HZ 3PH
Weight:
8000 Kg
Core Components:
Motor, Bearing, Gear, Pump, Engine, PLC
Steel Plant Thickness:
0.3-0.60mm
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Packaging Details
Main machine is nude,the computer control box is packed by plastic.
Delivery Time
30days
Payment Terms
T/T,Western Union,L/C
Supply Ability
35 sets per month
RELATED PRODUCTS
Good price IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof online Video

IBR and Corrugated Double Layer Roof sheet Roll Forming Machine For Ppgi Panel Roof

Get Best Price
Good price IBR Glazed Double Layer Roof sheet Roll Forming Machine 15m/Min For Ppgi Panel Roof online Video

IBR Glazed Double Layer Roof sheet Roll Forming Machine 15m/Min For Ppgi Panel Roof

Get Best Price
Good price Plc 0.80mm Double Layer Roll Forming Machine 15m/Min For Ppgi Panel Roof online Video

Plc 0.80mm Double Layer Roll Forming Machine 15m/Min For Ppgi Panel Roof

Get Best Price
Good price Double Layer Roll Forming Machine PLC Control online Video

Double Layer Roll Forming Machine PLC Control

Get Best Price
Contact Us
86-317-2016816
Contact Now
Product Description

Double Layer Panel Roll Forming Macihine Lines

Roofing tile machine, double layer roof wall machine can produce two or three types profile sheets, It's more cost effective than single layer machine and can save space and cost for you! .metal roof tile/panel is widely used in constructions and buildings,it can be uesd to build roof and wall.This kind of material can be used in many places such as gyms,warehouses,factories,etc.

Equipment Detailed Parameters:



1

Suitable MaterialPPGI (235Mpa)

2

roller material45# steel plated with chrome
3Rows of rollers15 rows & 16 rows
4Way of drivechaindrive,Gearbox drive(optional)
5

Product automatic stacker

6m length

6Feeding width1220mm
7Production Capacity12 m/min

8

Rolling thinckness

0.3-0.8m
9Diameter of shaft￠75mm

10

Voltage380V 50Hz 3phases
11main motor power5.5kw
12hydraulic station power4kw

Guarantee



1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation



Payment terms



40% in advance as down payment

60% is paid before the shipment is processed



Delivery



FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
