Metal Sheets 4kw Steel Plate Embossing Machine For Diamond Checker Sheet

Metal Sheets 4kw Steel Plate Embossing Machine For Diamond Checker Sheet

4kw metal sheets embossing machine

4kw steel plate embossing machine

diamond checker steel plate embossing machine

Place of Origin:

CHINA MAINLAND

Brand Name:

CANGZHOU FMS

Certification:

ISO CE

Model Number:

Embossing

Contact Us
Request A Quote
Product Details
Product Name:
Metal Embossing Floor Deck Roll Forming Machine
Condition:
New
Dimension(l*w*h):
7500*1700*1600Mm
Warranty:
1 Year
Power(w):
4kw
Control System:
PLC
Highlight:

4kw metal sheets embossing machine

,

4kw steel plate embossing machine

,

diamond checker steel plate embossing machine

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
40' FLC
Delivery Time
30 Working Days
Payment Terms
L/C, T/T, D/A, D/P
Supply Ability
20 Sets Per Month
Product Description

Metal Sheets Steel Plate Diamond Checker Sheet Embossing Machine



embossing machines are mainly for producing embossed aluminum and stainless metal sheets. metal embossing production line is suitable for metal sheet, particle board, decorated materials, and so on. The pattern is clear and has strong third-dimension. It can be assorted with the embossing production line

Specification

No. Item Description
1 Coil Galvalume, Galvanized, PPGI, Aluminum
2 Raw Material Thickness 20-30 GA
3 Working Speed 3-5 m/min ( not including the cutting time)
4 Roller Station 16 Raws
5

Dimension (L*W*H)

7500 mm*1500 mm*1500 mm
6 Machine Weight 5800 KG
7

Electrical Control System

Panasonic PLC (can be customized)

8

Drive Motor Power

7 KW
9

Hydraulic Station Power

5 KW
10

Power Supply

240V, 60HZ, 3 PHASES(can be customized)

11

Cutting Accuracy

±2 mm

12

Driving Mode

Single Chain 1 inch

13

Material of Shaft

70 mm 45#steel forged

14 Material of Roller

45# Steel Finish Machining, Plated Hard



Application



Small embossing machine, rolling floor deck with lightweight, heavy-duty bearings, beautiful appearance, seamless, good and convenient installation. It has been widely used in power plants, power equipment companies, automobile exhibition halls and steel structure seminars, cement warehouses, steel structure offices, airport docks, train stations, sports stadiums, music halls, music halls, large theaters, large supermarkets, logistics centers, Olympic Games venues, sports stadiums, and many other steel structure buildings



Advantage


1. Stable performance: The steel plate decoiler has uniform feeding speed and high stability.
2. Work: hydraulic synchronization and hydraulic punching system, improve work efficiency, precision and quality of finished products.
3. Good quality of the finished product: the floor deck produced by it is light in weight, heavy in load, and good in performance.


Metal Sheets 4kw Steel Plate Embossing Machine For Diamond Checker Sheet 0
