Product Details:
|
Voltage: | 380V/50HZ/3Phase | Power: | 7.5KW |
---|---|---|---|
Control System: | PLC | Material: | Galvanized Steel |
Weight: | 4.5T | Product Name: | Floor Deck Roll Forming Machine |
Roller Diameter: | 70mm | Shaft Diameter: | 50mm |
High Light: | 45 steel deck roll forming machine,excellent performance deck roll forming machine,7.5KW metal deck roll forming machine |
Our floor deck roll forming machine is the perfect choice for making galvanized steel floor decking steel sheets. It features a thickness of 0.3-0.8mm, 13-18 roller stations, 45# steel roller material, 7.5KW power, and a 50mm shaft diameter. It is a highly precise and reliable machine that produces superior quality floor deck sheets with exceptional consistency. It is also equipped with advanced safety features for maximum safety during operation. With its user-friendly interface, the floor deck roll forming machine can be easily operated and monitored, making it ideal for those who need to make high-quality floor deck sheets in a short amount of time.
Technical Parameters | Value |
---|---|
Cutting Tolerance | ±2mm |
Material | Galvanized Steel |
Weight | 4.5T |
Power | 7.5KW |
Voltage | 380V/50HZ/3Phase |
Thickness | 0.3-0.8mm |
Roller Stations | 13-18 Stations |
Shaft Material | 45# Steel |
Roller Material | 45# Steel |
Cutting Mode | Hydraulic Cutting |
The Floor Deck Roll Forming Machine is suitable for producing close type floor deck and galvanized steel floor decking steel sheet. This machine is powered by a 7.5KW motor and features a 45# steel shaft and 70mm roller diameter. The shaft diameter of the Floor Deck Roll Forming Machine is 50mm. This machine is highly efficient and can produce large quantities of floor decks at high speed. It is also energy-efficient and cost-effective. This machine is widely used in the construction industry to produce floor decks for residential and commercial buildings. It can also be used in the manufacturing of steel plates for various industrial and commercial applications. The machine is also suitable for producing galvanized steel floor decking steel sheets for use in roofing, wall cladding, and other applications. The machine is easy to operate and maintain, and it is also highly reliable and durable.
We provide technical support and services for Floor Deck Roll Forming Machine. Our services include:
Packaging and Shipping for Floor Deck Roll Forming Machine:
The floor deck roll forming machine will be packaged in a wooden box with a foam lining for extra protection. The box will be labeled with the product name, model number, and serial number. After the machine is packaged, it will be shipped out within 2-4 business days.
