Product Details:
Payment & Shipping Terms:
|
Product Name: | Shutter Door Roll Forming Machine | Roller Stations: | 18 Stations |
---|---|---|---|
Dimension: | 6.5m*0.95m*1.2m | Cutting Type: | Hydraulic Cutting |
Forming Speed: | 0-15m/min | Material: | Galvanized Steel Coil, Galvalume Steel Coil |
Voltage: | 380V/50Hz/3Phase | Thinckness: | 0.8-1.2mm |
High Light: | 15m/min shutter door roll forming machine,18stations shutter door roll forming machine,hydraulic cutting shutter door rolling machine |
This roller shutter machine is a professional rolling shutter machine, which is designed for the production process of high-precision shutter doors. It features advanced hydraulic cutting technology, and the roller material is made of 45# steel, providing a better performance. With an overall weight of 1T and a power of 7.5KW, this shutter bottom roll forming machine is reliable and stable. It is also provided with a 1-year warranty, ensuring its quality and performance.
Parameter | Value |
---|---|
Cutting Type | Hydraulic Cutting |
Forming Speed | 0-15m/min |
Roller Stations | 18 Stations |
Roller Material | 45# Steel |
Dimension | 6.5m*0.95m*1.2m |
Weight1 | 1T |
Thinckness | 0.8-1.2mm |
Power | 7.5KW |
Voltage | 380V/50Hz/3Phase |
Material | Galvanized Steel Coil, Galvalume Steel Coil |
FMS is a professional manufacturer of rolling shutter machines, and their shutter door roll forming machine is an ideal solution for all rolling shutter needs. With a CE certified design and a minimum order quantity of 1 set, this roller shutter machine is an excellent choice for customers. With a competitive price of 10000, this machine is also extremely cost-effective. The packaging details are naked with plastic film, and the delivery time is 45 days. The payment terms are T/T, L/C, and the supply ability is 20 sets per month. The thickness of the product is 0.8-1.2mm, while the forming speed is 0-15m/min. The voltage is 380V/50Hz/3phase, and the warranty offered is 1 year. The cutting type is hydraulic cutting.
Customized Service for the Shutter Door Roll Forming Machine
Our technical support and services for Shutter Door Roll Forming Machines include:
Packaging and Shipping for Shutter Door Roll Forming Machine:
