Name: Metal Stud & Track Roll Former Machine With Punching
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Stud and Track
Price: 40,500.00 USD
Availability: InStock

Home > products > Stud And Track Roll Forming Machine >

Metal Stud & Track Roll Former Machine With Punching

Metal Stud Track Roll Former Machine

Metal Stud Track Roll Former

Punching stud roll forming machine

Place of Origin:

CHINA MAINLAND

Brand Name:

FMS

Certification:

ISO CE

Model Number:

Stud and Track

Request A Quote

Product Details

Product Name:

Metal Stud & Track Roll Former Machine Roll Former With Punching

Dimension(L*W*H):

5500 Mm*1000 Mm*1500 Mm

Raw Material:

Galvalume, Galvanized

Working Speed:

20 - 40 M/min

Widths Of Stud:

3 1/2″, 5 1/2″

Gauge:

24 Gauge -16 Gauge

Motor Power:

4KW

Pow Supply:

220v 3 Phase 60hz

Profile:

As Customer Requested

Flange Track:

3.6 & 5.6 X 2.125

Highlight:

Metal Stud Track Roll Former Machine

Metal Stud Track Roll Former

Punching stud roll forming machine

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

Negotiable

Packaging Details

20' FLC

Delivery Time

30 Working Days

Payment Terms

L/C, T/T, D/A, D/P

Supply Ability

20 Sets Per Month

High Efficiency Stud And Track Roll Forming Machine 50 M / Min PLC Control

Get Best Price

Video

Metal Decorative Stud And Track Roll Forming Machine 0.3mm - 0.8mm Thickness

Get Best Price

Video

Low Noise Metal Roof Panel Machine Steel Stud Roll Forming Machine 240V 60HZ

Get Best Price

Video

Commercial Acoustic Stud And Track Roll Forming Machine 20-30 GA Thickness

Get Best Price

86-317-2016816

Contact Now

Product Description

Metal Stud & Track Roll Former Machine Roll Former With Punching

The sMetal Stud & Track Roll Former Machine Roll Former With Punching for use in commercial and domestic buildings where it is necessary to provide strong non-load-bearing partitions.
There is a wide range of partition thickness available for heights of up to 12m. The system is economical and can be erected easily. When installing the system, it is advisable to use and electrically or battery-operated screw gun. It is necessary to ensure that electric cables can pass through the studs that are protected by grommets.

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized
2	Raw Material Thickness	0.4-0.6mm
3	Working Speed	20-40 m/min
4	Roller Station	12 Raws
5	Dimension (LWH)	5500 mm1000 mm1500 mm
6	Machine Weight	1500 KG
7	Electrical Control System	Delta PLC (can be customized)
8	Flange Track	3.6 & 5.6 x 2.125
9	Hydraulic Station Power	4 KW
10	Power Supply	220v 3 phase 60hz(can be customized)
11	Cutting Accuracy	±2 mm
12	gauge	24 gauge -16 gauge
13	Profile	as customer requested
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Advantage

The metal system is accurate and solid, and will not move over time or with changes in temperature.
There is a wide range of stud widths from 50mm to 146mm to meet varying requirements.
It is a fast and clean system to erect that allows services to pass through easily.
All sections fit together easily and door frames are formed very simply.

Payment terms

30% in advance as down payment

70% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
