380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw

380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw

380Volt Shutter Door Roll Forming Machine

Shutter Door Roll Forming Machine 22Kw

roller shutter door making machine 22Kw

Place of Origin:

CHINA MAINLAND

Brand Name:

CANGZHOU FMS

Certification:

ISO CE

Model Number:

Shutter Door

Contact Us
Request A Quote
380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw
380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw 380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw 380Volt PU Sandwich Shutter Door Roll Forming Machine Making Machine 22Kw
Product Details
Product Name:
PU Sandwich Shutter Door Roll Forming Machine Making Machine Manufactures Prices
Raw Material:
Galvalume, Galvanized, PPGI
Working Speed:
8-15m/min
Thickness:
0.3-0.8mm
Voltage:
380V 50Hz, 380V.50HZ.3Phase
Weight:
9000 Kg
Cutting Blade Material:
Cr 12 High Grade Steel
Cutter Material:
CR12
Power:
22Kw
Roll Material:
45# High Grade Steel
Highlight:

380Volt Shutter Door Roll Forming Machine

,

Shutter Door Roll Forming Machine 22Kw

,

roller shutter door making machine 22Kw

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
20' FLC
Delivery Time
30 Working Days
Payment Terms
L/C, T/T, D/A, D/P
Supply Ability
20 Sets Per Month
RELATED PRODUCTS
Good price Customized High Speed PU Door Roller Shutter Roll Forming Machine online Video

Customized High Speed PU Door Roller Shutter Roll Forming Machine

Get Best Price
Good price 3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size online Video

3T Shutter Door Roll Forming Machine For 0.8-1.2mm Thickness And 6.5m*0.95m*1.2m Size

Get Best Price
Good price 45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System online Video

45 Steel Roller Material Shutter Door Roll Forming Machine with 7.5KW PLC Control System

Get Best Price
Good price PLC Control System 3T Shutter Door Roll Forming Machine For Doors online Video

PLC Control System 3T Shutter Door Roll Forming Machine For Doors

Get Best Price
Contact Us
86-317-2016816
Contact Now
Product Description

PU Sandwich Shutter Door Roll Forming Machine Making Machine Manufactures Prices



  Put the steel coil on the un-coiler----Feeding guide equipment----Roll-forming Machine----Foaming machine ----Adjusting device ----Punching device----Flying saw cutting-----finished products on stacker



   This foaming aluminum shutter forming machine integrates cold roll forming technology and PU foaming technology into one, thuscontinuous automation production of foaming roller shutter door is achieved.

PU Sandwich Shutter Door Roll Forming Machine

  1. Rolling up and down, the noise is smaller, the work is quieter, which means less damage to the door every day, longer working hours, and more suitable for human care in some crowded areas.

  2. PU shutter doors and windows are sound absorbing materials, so once you shake the shutter door, most of the street sound will be absorbed by the foam in the shutter door.

  3. Fireproof and energy saving: The foam density is large, which can save area energy and fire. Therefore, it is highly recommended to install the main door and window in a safer and more economical room.



Specification

Warranty of core components
1 Year
Voltage
380V 50Hz
Weight
9000kg
Production Capacity
5-8m/min
Power
22Kw
Dimension(L*W*H)
20*1*1.2m
Applicable Material
UPVC, Aluminum
Production Capacity
8-15M/Min
Voltage
380V.50HZ.3Phase
Weight
9000 kg
Roll material
45# high grade steel
Cutting blade material
Cr 12 high grade steel
Frame material
300 H-high grade steel
Core Components
Motor, PLC
Roll stations
18 rows
Rolling thinckness
0.3-0.8mm
Dimension(L*W*H)
20*1*12m



Guarantee





  1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

  2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation



Payment terms



  40% in advance as down payment

  60% is paid before the shipment is processed



Delivery



  FOB: Tianjin Xingang Port

  The Delivery Time: 30 days after the down payment is received.
