Home > products > Highway Guardrail Roll Forming Machine >

Gearbox Driven 3mm Highway Guardrail Roll Forming Machine

3mm highway guardrail roll forming machine

gearbox highway guardrail roll forming machine

gearbox driven guardrail roll forming machine

Place of Origin:

China

Brand Name:

FMS

Certification:

CE,ISO

Request A Quote

Product Details

Voltage:

380V 50Hz 3phases Or As Per Customer Requirements

Roller Material:

High Grade #45 Steel With Hard Chromed

Product Name:

2 Waves 3 Waves 3mm Highway Guardrail Roll Forming Machine Cold Rolled Coil

Raw Material:

Cold Rolled Coil, Hot Rolled Coil, Galvanized Coil

Cutting Blade Material:

Cr12Mov With Quench HRC58-62°

Warranty:

2years

Marketing Type:

Hot Product

Tile Type:

Steel

Highlight:

3mm highway guardrail roll forming machine

gearbox highway guardrail roll forming machine

gearbox driven guardrail roll forming machine

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

Negotiable

Packaging Details

Main machine is nude,the computer control box is packed by plastic.

Delivery Time

50days

Payment Terms

T/T, Western Union, D/A, L/C

Supply Ability

10 sets per month

350Mpa Yield Strength Highway Guardrail Roll Forming Machine With 400H Beam Structure

Get Best Price

Video

Gcr15 Rollers Highway Guardrail Roll Forming Machine 350Mpa Yield Strength 380V 50Hz Power Supply

Get Best Price

Video

GI Highway Guardrail Roll Forming Machine With Cutting Blade Material Cr12Mov And Roller Diameter 80mm

Get Best Price

Video

GI Materials Highway Guardrail Roll Forming Machine With 380V 50Hz Power Supply And 350Mpa Yield Strength

Get Best Price

86-317-2016816

Contact Now

Product Description

Highway Guardrail Roll Forming Machine With Gearbox Driven Highway Guard

Highway guardrail forming machine is a guardrail machine used to produce highway industry, and the finished product is highway guardrail. It is mostly used in safety guardrails on highways, national roads, provincial roads, urban roads, rural roads and other motor vehicle lanes.

2.Equipment Detailed Parameters:

No
1	Suitable Material	Cold rolled coil, hot rolled coil, galvanized coil
2	Width of the raw material	480mm
3	Rows of rollers	15 rows
4	Total power	Main motor 22kwx2 Hydraulic station power 4kw
5	Thickness of raw material	2.5-3mm
6	Speed	10-12m/min
7	Diameter of shaft	￠116mm
8	Voltage	380V 50Hz 3phases
9	Big frame	400H steel
10	Middle plate	18mm

Gearbox Driven 3mm Highway Guardrail Roll Forming Machine 0

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 20 days after the down payment is received.

Tags：

crash barrier roll forming machine

highway guardrail making machine

guard rail roll forming machine
