Name: Duplex Metal Stud Roll Forming Machine Hydraulic Motor 5 KW Easy Operation
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Stud and Track
Price: 40,500.00 USD
Availability: InStock

Home > products > Stud And Track Roll Forming Machine >

Duplex Metal Stud Roll Forming Machine Hydraulic Motor 5 KW Easy Operation

ridge cap roll forming machine

roof tile roll forming machine

Place of Origin:

CHINA MAINLAND

Brand Name:

CANGZHOU WILLING

Certification:

ISO CE

Model Number:

Stud and Track

Request A Quote

Product Details

Product Name:

Duplex Internal Stud Wall Framing Machine Stud And Track Roll Forming Machine

Dimension(L*W*H):

6500 Mm*1500 Mm*1500 Mm

Raw Material:

Galvalume, Galvanized

Working Speed:

30 M/min - 50 M/min

Color:

Customzied

Delivery:

30 Working Days

Highlight:

ridge cap roll forming machine

roof tile roll forming machine

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

Negotiable

Packaging Details

20' FLC

Delivery Time

30 Working Days

Payment Terms

L/C, T/T, D/A, D/P

Supply Ability

20 Sets Per Month

High Efficiency Stud And Track Roll Forming Machine 50 M / Min PLC Control

Get Best Price

Video

Metal Decorative Stud And Track Roll Forming Machine 0.3mm - 0.8mm Thickness

Get Best Price

Video

Low Noise Metal Roof Panel Machine Steel Stud Roll Forming Machine 240V 60HZ

Get Best Price

Video

Commercial Acoustic Stud And Track Roll Forming Machine 20-30 GA Thickness

Get Best Price

86-317-2016816

Contact Now

Product Description

Duplex Internal Stud Wall Framing Machine Stud and Track Roll Forming Machine

DUPLEX Internal Stud Framing System is one Stud that does the job of two.

It’s perfect for door openings and glazing in internal wall framing applications where you typically need to install a boxed stud configuration. Less products to install means much quicker installations, delivering you with the all-important labour cost savings.

Profile

Duplex Metal Stud Roll Forming Machine Hydraulic Motor 5 KW Easy Operation 0

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized
2	Raw Material Thickness	20-30 GA
3	Working Speed	30-50 m/min
4	Roller Station	14 Raws
5	Dimension (LWH)	6000 mm1500 mm1500 mm
6	Machine Weight	4500 KG
7	Electrical Control System	Panasonic PLC (can be customized)
8	Drive Motor Power	7.5 KW
9	Hydraulic Station Power	5 KW
10	Power Supply	240V, 60HZ, 3 PHASES(can be customized)
11	Cutting Accuracy	±2 mm
12	Driving Mode	Single Chain 1 inch
13	Material of Shaft	60 mm 45#steel forged
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.

Duplex Metal Stud Roll Forming Machine Hydraulic Motor 5 KW Easy Operation 1
