Metal Roofing Downpipe Roll Forming Machine Rainwater Downspout

Metal Roofing Downpipe Roll Forming Machine Rainwater Downspout

PLC Downpipe Roll Forming Machine

10m/min Downpipe Roll Forming Machine

15m/min Downpipe Forming Machine

Place of Origin:

CHINA

Brand Name:

CANGZHOU FMS

Certification:

ISO CE

Model Number:

Square/Round Down Spout

Contact Us
Request A Quote
Product Details
Product Name:
Metal Roofing Downpipe Making Machinery Roll Forming Machine Rainwater Downspout
Production Capacity:
10-15m/min
Weight:
6500 Kg
Thickness:
0.3-0.8 Mm
Control System:
PLC
Feeding Width:
1220mm
Voltage:
380V 50Hz 3phases Or As Your Requirement
Highlight:

PLC Downpipe Roll Forming Machine

,

10m/min Downpipe Roll Forming Machine

,

15m/min Downpipe Forming Machine

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
20' FLC
Delivery Time
30 Working Days
Payment Terms
L/C, T/T, D/A, D/P
Supply Ability
20 Sets Per Month
Product Description

Metal Roofing Downpipe Making Machinery Roll Forming Machine Rainwater Downspout



   Metal Roofing Downpipe Making Machinery Roll Forming Machine Rainwater Downspout Advantage of steel :
Galvanized steel guttering resists thermal expansiono and contraction,which means that it remains unaffected from sudden fluctuations in temperature.Steel has an excellent lifetime value,as it can be recycled.
The downpipe forming machine we produced is customized according to the specific requirements of customers.Such as specification and raw materials, The machine is intalled and tested before leaving the factory.
After receiving the machine, the customer can start production once connect wires and tubes.We randomly send instructions to tell how to operate. Of course, we also have corresponding videos for reference.
Technicians Can also be sent to customer factory for guidance and training if necessary.
The downpipe roll forming machine also work with elbow bending machine,

which make flat pipe to curve according to construction requirement.



Specification



No. Item Description
1 Coil PPGI
2 Loading weight 3T
3 Thickness of Material 0.4-0.6mm
4 Roller Station 26 Stations
5

Dimension (L*W*H)

8000 mm*800 mm*1200 mm
6 Forming Speed 10-15m/min
7

Electrical Control System

PLC

8

Diameter of Shaft

¢70mm
9

Main Power

7.5KW
10

Power Supply

380V, 60HZ, 3 PHASES(can be customized)

11

Cutting Accuracy

± 2 mm

12

Hydraulic Power

7.5KW

13

Material of cutter blade

Cr12 steel with quenched treatment



Installation


  During the installation and adjustment of the equipment, our engineers shall provide the training to the buyer’s personal request to operate and  maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation, and non-standard safety items, testing material and etc.



Guarantee



  The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during the guarantee period, we will provide the parts free of charge, which is in the conditions of correct operation. (Natural disasters or factors which can’t be forced by human are excluded).



Payment terms



  40% in advance

  60% is paid before shipping
